Ringer Operating Instructions
BT type 700 phone
BT Duet 200 phone

Insert the DC Power plug into the socket on the rear of the ringer unit marked +12vdc. Ensure the "Regulated plug in power supply" is set to 12v output.

Plug in any working telephone fitted with a BT or RJ11* jack, to either of the sockets at the rear of the ringer unit.

Plug the power supply into the ac mains, the status and P.S.U. indicators should now light up (Red).

Choose your model and set the cadence switch to your preference from table below.

To begin the ringing process press the green start button, the status indicator will flash green and the phone will ring, it will stop as soon as the receiver is lifted. If the phone is to be left unanswered, press the red stop button to cancel the ringing when required. The Status indicator will light up yellow when either the phone is off the hook or the stop button is pressed on the 6 Cadence model.

*via adaptor

6 cadence + Manual option model

3 cadence model

Telephone Ring Generator world cadences

Click to  enlarge front and rear view of 6 cadence + manual option model

UK

0.4sec ON

0.2sec OFF

0.4sec ON

2.0sec OFF



USA

2.0sec ON

4.0sec OFF



EU

Germany

Italy

Netherlands

Norway

Sweden

Switzerland

1.0sec ON 4.0sec OFF

Belgium

1.0sec ON

3.0sec OFF



Asia

1.0sec ON

2.0sec OFF

E.G Japan Israel

France

1.65sec ON

3.35sec OFF



Manual

 User set

Telephone Ring Generator - phone stage ringer

Click to  enlarge front and rear view of 3 cadence model

USA

2.0sec ON

4.0sec OFF



UK

0.4sec ON

0.2sec OFF

0.4sec ON

2.0sec OFF

USA  short

1.0sec ON

2.0sec OFF
